Steel Door Punching Machine Door Frame Punch Press

A steel door punching machine is a specialized piece of equipment designed to create various shapes, patterns, and cutouts in steel doors. This machine uses punching dies and hydraulic or mechanical systems to apply force, making precise and consistent cutouts in the door panels for various applications, such as residential, commercial, and industrial doors.

Key features of a steel door punching machine include:

1. Punching dies: The punching dies are the tools used to create the desired shapes, patterns, or cutouts in the steel doors. They are made of high-quality materials, such as hardened steel or carbide, to ensure durability and precision. Punching dies can be customized to meet specific design requirements.
2. Drive system: The drive system, often comprising hydraulic or mechanical systems, powers the punching process and ensures the smooth operation of the machine. Hydraulic systems generally offer greater control over force and speed, while mechanical systems may be simpler and more cost-effective.

Main Technical Parameters:

1) Nominal pressure 400KN

2) Nominal pressure stroke: 4mm

3) Slide stroke: 80mm

4) Slide strokes per minute: 50 S. P. M.

5) Max. die set height: 230mm

6) Die set height adjustment: 45mm

7) Distance from slider center to machine body: 220mm

8) Working table size: 390mm*630mm

9) Working table hole size: ￠155mm

10) Working table thickness: 70mm

11) Slider bottom size: 210mm*250mm

12) Punch shank hole size Diameter: ￠50mm

13) Distance between columns: 330mm

14) Motor Power: 4 KW
